Showing 2191–2205 of 5161 results
IFF Pole Operated Pantograph suspends and positions luminaires with loads of up to 40kg (88 Lbs). It is a versatile suspension unit for small, medium and large studios.
The pantograph can be extended via twin wire ropes. The self-locking drum winch with two steel cables support loads under static and dynamic conditions. The specially designed double scissors mechanism adds extra stability and is furnished with cable clips to support luminaire power cables. It is dynamically and statically irreversible thanks to its static and dynamic efficiency (<0.5). The pantograph is manufactured in accordance with the DIN 15560-46. Closed height 0.66 m.
IFF Pole Operated Pantograph suspends and positions luminaires with loads of up to 40kg (88 Lbs). It is a versatile suspension unit for small, medium and large studios.
The pantograph can be extended via twin wire ropes. The self-locking drum winch with two steel cables support loads under static and dynamic conditions. The specially designed double scissors mechanism adds extra stability and is furnished with cable clips to support luminaire power cables. It is dynamically and statically irreversible thanks to its static and dynamic efficiency (<0.5). The pantograph is manufactured in accordance with the DIN 15560-46. Closed height 0.78 m.
The TOP 2C is a manual operated friction pantographs for single loads of up to 18 kg (39.7 Lbs). TOP 2C extends 2 m.
The innovative design of the pantograph allows lights to be placed closer to the ceiling than ever before. A complete new range of top and bottom attachments have been designed to reduce at minumum the closed length. Entirely produced in Aluminum (P-Al MgSi UNI3569) and according to DIN 15560-46. The load is supported by a steel cable of 2 mm diameter (safety factor 12). Loads up to 12 kg (26.4 Lbs) can be supported by the patented friction device, while loads up to 18 kg (39.7 Lbs) require the use of optional springs.
The TOP 4C is a manual operated friction pantographs for single loads of up to 18 kg (39.7 Lbs). TOP 2C extends 3.8 m.
The innovative design of the pantograph allows lights to be placed closer to the ceiling than ever before. A complete new range of top and bottom attachments have been designed to reduce at minumum the closed length. Entirely produced in Aluminum (P-Al MgSi UNI3569) and according to DIN 15560-46. The load is supported by a steel cable of 2 mm diameter (safety factor 12). Loads up to 12 kg (26.4 Lbs) can be supported by the patented friction device, while loads up to 18 kg (39.7 Lbs) require the use of optional springs.
Manual, pole operated pantograph for single loads of up to 40kg (88Lbs).
The self-locking drum winch mechanism with two steel cables support loads under static and dynamic conditions. The specially designed sheet metal scissors add stability and are furnished with cable clips for power cables. Closed height 0.78 m.
Manual, pole operated pantograph for single loads of up to 40kg (88Lbs).
The self-locking drum winch mechanism with two steel cables support loads under static and dynamic conditions. The specially designed sheet metal scissors add stability and are furnished with cable clips for power cables. Closed height 0.99 m.
Additional spring for pantograph.
Spring usage:
Without spring: From 0 to 4kg (8.8lbs)
Type 4: From 3kg (6.6lbs) to 8kg (17.6lbs)
Type 4 + Type 4: From 8kg (17.6lbs) to 14kg (30.8lbs)
Type 12: From 9kg (19.8lbs) to 16kg (35.3lbs)
Type 4 + Type 12: From 13kg (28.6lbs) to 18kg (39.7lbs)
Additional spring for pantograph.
Spring usage:
Without spring: From 0 to 4kg (8.8lbs)
Type 4: From 3kg (6.6lbs) to 8kg (17.6lbs)
Type 4 + Type 4: From 8kg (17.6lbs) to 14kg (30.8lbs)
Type 12: From 9kg (19.8lbs) to 16kg (35.3lbs)
Type 4 + Type 12: From 13kg (28.6lbs) to 18kg (39.7lbs)
Avenger A2020 Column C-Stand 20 Chrome 95/206cm Weighs 2.8kg
Avenger C1000 Clamp Scissor Drop Ceiling 5/8 Male Spigot Mount L5.72cm Zinc Steel w0.17kg
Avenger A2018L Stand Light C-Stand 18L 84-170cm 8kg Payload Chrome w Sliding leg w4.3kg
