Dimmers and power distribution
TecArt Motor Controller 8 way
Contact us for dealer pricing.
The Motor Controller is designed to operate electric chain hoists. The unit includes main breaker, indicators on mains input and forward/reverse switch. Indicators demonstrate up, down and off for each channel. Output via Weiland 6-pin or 16-pin connector. Unit is available in 4-way and 8-way options.
SKU: n/a -
Dimmers and power distribution
TecArt Power Distribution Rack Mount 12 channel 2.5kW
Contact us for dealer pricing or custom configurations.
The TecArt power distribution system is designed for permanent or touring applications where power distribution is required. The unit features an MCB and RCD (Residual Current Device) per channel. The TecArt distro is suitable for the standard 19 inch equipment rack.
SKU: n/a -
Dimmers and power distribution
TecArt Power Distribution Rack Mount 400A 4 way
Contact us for dealer pricing.
The TecArt power distribution system is designed for permanent or touring applications where power distribution is required. The unit features a main Residual Current Device (RCD), main 3 phase circuit breaker and individual breaker per output. The TecArt distro is suitable for the standard 19 inch equipment rack.
The 4-way variant features 400A power lock in/out, with four 32A 3 phase outputs at the back and three 20A single phase outlets at the front.
SKU: n/a -
Dimmers and power distribution
TecArt Power Distribution Rack Mount 400A 5 way
Contact us for dealer pricing.
The TecArt power distribution system is designed for permanent or touring applications where power distribution is required. The unit features a main Residual Current Device (RCD), main 3 phase circuit breaker and individual breaker per output. The TecArt distro is suitable for the standard 19 inch equipment rack.
The 5-way variant features 400A power lock in/out, with five 32A 3 phase outputs across the top and back and three 20A single phase outlets at the back.
SKU: n/a -
Data and DMX distribution
TecArt RDM Toolbox in a Pelican Case
The TecArt RDM Toolbox is a diagnostic tool for professional lighting technicians.
FEATURES
• DMX Transmit and Receive (512 channels).
• DMX Testing.
• Remote DMX Addressing (with compatible luminaires).
• RDM Discovery.
• RDM Query and Device Configuration.
• RDM Monitoring.
• Rugged Pelican™ Water and Dust-resistant Case.
• Battery-powered.SPECIFICATIONS
• Supply: 240VAC.
• Internal Battery: Rechargeable.
• DMX In/Out: 5-pin XLR.SKU: n/a -
Dimmers and power distribution
TecArt Relay Single Channel 2.5kW
The Relay Single Channel 2.5K is an Australian designed and manufactured high performance contactor for the professional entertainment and production market. A number of options are available, the main option being the inclusion of an LED display and keypad, to enable extended functionality. The unit has a switch for local activation or the option of DMX control.
FEATURES
• Thermal-magnetic circuit breaker protection of outputs.
• DMX status LED.
• DMX-512 control.
• Single phase operation.
• Supplied with standard 10A outlet and power feed cable.SKU: n/a -
Dimmers and power distribution
TecArt Relay VX Rack Mount 12 channel
The TecArt series of 19” rack-mount relay racks are an Australian designed and manufactured high-performance relay rack for the professional entertainment and production market. The unit features full 512 channel start address. An LCD and keypad enable functionality such as soft-patch, internal memory scene and interactive test mode.
FEATURES
• Thermal-magnetic circuit breaker protection of outputs.
• DMX status LED and phase 1/2/3 LEDs.
• LED indicators for channel operation.
• LCD for DMX addressing and temperature.
• Soft-patch.
• Simple test functions per channel built-in.
• DMX-512 control.
• Single or three phase operation.
• Internal quiet fan with microprocessor auto control.
• Available with standard 10A outlets, Weiland, Socapex or hard wired.
• Supplied with 1.5m mains cable and plug.SKU: n/a -
Fluorescent and tungsten lighting
TecArt Retrofit KinoFlo Ballast 2 bank
This ballast type is compatible with no modifications for the following KinoFlo models:
• 4 Bank System.
• 2 Bank System.
• Single System.
• Mega Double System.
• Mega Single System.FEATURES
• Better performance.
• Greater reliability.
• Higher output.
• Perfect colour temperature.
• 240V operation.
• Very competitively priced.SKU: n/a -
Fluorescent and tungsten lighting
TecArt Retrofit KinoFlo Ballast 4 bank
This ballast type is compatible with no modifications for the following KinoFlo models:
• 4 Bank System.
• 2 Bank System.
• Single System.
• Mega Double System.
• Mega Single System.FEATURES
• Better performance.
• Greater reliability.
• Higher output.
• Perfect colour temperature.
• 240V operation.
• Very competitively priced.SKU: n/a -
Fluorescent and tungsten lighting
TecArt Retrofit KinoFlo Ballast card
This is a direct swapover card requiring no modifications for all KinoFlo ballast models, including 2ft, 4ft Single, Double, 4 Bank, 6ft & 8ft Mega Lights and Wall-o-lights.
FEATURES
• Better performance.
• Greater reliability.
• Higher output.
• Perfect colour temperature.
• 240V operation.
• Pin-to-pin direct replacement.
• Very competitively priced.SKU: n/a -
Fluorescent and tungsten lighting
TecArt Retrofit KinoFlo Ballast single
This ballast type is compatible with no modifications for the following KinoFlo models:
• 4 Bank System.
• 2 Bank System.
• Single System.
• Mega Double System.
• Mega Single System.FEATURES
• Better performance.
• Greater reliability.
• Higher output.
• Perfect colour temperature.
• 240V operation.
• Very competitively priced.SKU: n/a -
Data and DMX distribution
TecArt Splitter Desktop DMX 4 way
The TecArt range of data splitters are available as desktop units.
Each output has a separate driver and opto-isolator to ensure the highest possible level of protection.
The unit is available as a standard DMX splitter or with the option of RDM.
RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.
RDM or Remote Device Management is a protocol enhancement to DMX512 that allows Bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.
DMXS4DT can be supplied with an external 12 – 48VDC power supply.
FEATURES
• DMX-512 In/Out/Thru.
• External Power Supply 12 – 48VDC.
• 2 Main indication LEDs.SPECIFICATIONS
• Input voltage: 12 – 48VDC.
• Power supply: External.
• Total power: 6W @ 24VDC.
• Dimension: 105mm (L) 85mm (W) 60mm (H).
• Mounting method: Desktop.
• DMX signal input: XLR.
• DMX signal output: XLR.
• Outputs: 4 Opto isolated.
• Temperature: 0 – 40 degree Celsius.SKU: n/a -
Data and DMX distribution
TecArt Splitter Desktop RDM 4 way
The TecArt range of data splitters are available as desktop units.
Each output has a separate driver and opto-isolator to ensure the highest possible level of protection.
The unit is available as a standard DMX splitter or with the option of RDM.
RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.
RDM or Remote Device Management is a protocol enhancement to DMX512 that allows Bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.
DMXS4DT can be supplied with an external 12 – 48VDC power supply.
FEATURES
• DMX-512 In/Out/Thru.
• External Power Supply 12 – 48VDC.
• 2 Main indication LEDs.SPECIFICATIONS
• Input voltage: 12 – 48VDC.
• Power supply: External.
• Total power: 6W @ 24VDC.
• Dimension: 105mm (L) 85mm (W) 60mm (H).
• Mounting method: Desktop.
• DMX signal input: XLR.
• DMX signal output: XLR.
• Outputs: 4 Opto isolated.
• Temperature: 0 – 40 degree Celsius.SKU: n/a -
Data and DMX distribution
TecArt Splitter DIN Rail DMX 4 way
The TecArt range of data splitters are available as DIN Rail mountable units.
Each output has a separate driver and opto-isolator to ensure the highest possible level of protection.
The unit is available as a standard DMX splitter or with the option of RDM.
RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.
RDM or Remote Device Management is a protocol enhancement to DMX512 that allows Bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.
DMXS4DR can be supplied with an external 12 – 48VDC power supply.
FEATURES
• DMX-512 In/Out/Thru.
• External Power Supply 12 – 48VDC.
• Terminal Strip Output and Input Connector.
• 2 Main indication LEDs.SPECIFICATIONS
• Input voltage: 12 – 48VDC.
• Power supply: External.
• Total power: 6W @ 24VDC.
• Dimension: 105mm (L) 85mm (W) 60mm (H).
• Mounting method: DIN Rail.
• DMX signal input: Terminal block.
• DMX signal output: Terminal block.
• Outputs: 4 Opto isolated.
• Temperature: 0 – 40 degree Celsius.SKU: n/a -
Data and DMX distribution
TecArt Splitter DIN Rail RDM 4 way
The TecArt range of data splitters are available as DIN Rail mountable units.
Each output has a separate driver and opto-isolator to ensure the highest possible level of protection.
The unit is available as a standard DMX splitter or with the option of RDM.
RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.
RDM or Remote Device Management is a protocol enhancement to DMX512 that allows Bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.
DMXS4DR can be supplied with an external 12 – 48VDC power supply.
FEATURES
• DMX-512 In/Out/Thru.
• External Power Supply 12 – 48VDC.
• Terminal Strip Output and Input Connector.
• 2 Main indication LEDs.SPECIFICATIONS
• Input voltage: 12 – 48VDC.
• Power supply: External.
• Total power: 6W @ 24VDC.
• Dimension: 105mm (L) 85mm (W) 60mm (H).
• Mounting method: DIN Rail.
• DMX signal input: Terminal block.
• DMX signal output: Terminal block.
• Outputs: 4 Opto isolated.
• Temperature: 0 – 40 degree Celsius.SKU: n/a
