Data and DMX distribution

5 Configurable Ports: 5-pin XLR ports that can be individually set as DMX Input or Output with RDM support.
Show Control Gateway: Dedicated ports for MIDI (In/Out), LTC Timecode (In/Out), and 10Scene (for wall plate integration).
Software Unlocking: * Unlocks MagicQ PC to Full Mode via USB.
– Unlocks MagicQ PC to Reduced Mode via Network.
Flexible Mounting: Includes rack ears for 19″ racks, a DIN rail clip for cabinets, and an M12 receiver for truss mounting.
Local & Remote Setup: Built-in front panel display and encoder for quick changes, or use the internal web server for remote configuration.
Redundancy & Fail-safe: Supports DMX redundancy and features “Scene Store” to play back pre-programmed looks if the console signal is lost.

Weatherproof Performance: IP65 rating makes it dust-tight and protected against water jets, suitable for outdoor use.
Gigabit Speed: Five 10/100/1000 Mbps ports for high-speed data transfer.
Flexible Powering: Can be powered via Neutrik powerCON TRUE1 mains input or via PoE (Power over Ethernet) on the “PoE IN” port.
Rugged Connectivity: Features locking Ethernet connectors to prevent accidental disconnection during a show.
Rigging Options:
– M12 Threaded Insert: For direct clamp mounting.
– Safety Bond Rail: Built-in rail for a secondary safety attachment when rigged overhead.
Status Monitoring: Visible Port Status LEDs indicate active connections and whether they are running at Gigabit speed.

Chauvet DJ DataStream8
The Chauvet DJ Data Stream 8 is a flexible DMX splitter designed to distribute and boost incoming DMX signals from dual inputs into 8 separate outputs via a master 3-position switch. Each input can be used simultaneously and sent to any output. Individual 2-position switches can also send data from either the A or B input separately. Each of the outputs is optically isolated from the others providing protection in the event of a short. A threaded insert allows the unit to be safely secured to trussing.

Chauvet DJ DMX-AN2
The Chauvet DJ DMX-AN2 is a multi-purpose Art-Net/sACN node that converts 1 Ethernet cable to 2 DMX universes. Its optical and electrical isolation is ready for any situation and the durable Neutrik® etherCON® in/through port ensures reliability. The built-in web-based GUI means no universe/subnet setup. DMX-AN2 automatically redirects the web page if the IP address is changed. The unit supports Power over Ethernet (POE) or an external power supply. Both outputs can be set to either Art-Net or sACN and DMX-AN2 functions as an Art-Net to DMX or DMX to Art-Net interface. Onboard LED indicators quickly inform status and the integrated mounting bracket is included to quickly install into any location.

The Chauvet DJ XPRESS-RACK1024 is a rackmount DMX interface for ShowXpress software. Capable of controlling 2 DMX universes while also unlocking an additional ArtNet universe; giving you 3 universes total. As a result, you can easily store and playback up to 16 shows without a computer; using either the onboard buttons or by the included remote.

• Expansion module for DMXcat
• Supports Ethernet Proocols, ArtNet, sACN
• Test 5-Pin XLR and Ethernet Cables
• View PoE Voltages and DMX Timings

Contact us for dealer pricing.

The ArtNode 2 is an ArtNet to dual-purpose DMX node for architectural and entertainment lighting control applications.

FEATURES
• Multi mode: ArtNet to DMX, 2 x DMX to ArtNet.
• External power supply 9-24VDC (supplied separately).
• Robust housing.
• 2 main indication LEDs.

SPECIFICATIONS
• Input Voltage: 9–24VDC.
• Power: 6VA (at 24VDC).
• Dimensions (mm): 117 L x 115 W x 53 H.
• Mounting Options: Desk-mount.
• DMX Input/Output: 5-pin XLR.
• Outputs: 2 x DMX Universes.
• Inputs: 1x Ethernet
• Operating Temperature: 0 – +40°C.

Contact us for dealer pricing.

The DEMUX Rack Mount is a DMX to 0-10V converter, allowing analogue devices to be controlled via DMX. The unit can deliver either negative or positive control voltage.
