Backstage Long John Silver Junior Cart (Avenger)

The Deploy (2023) is a mobile vertical rack-mount workstation with 16U of space accessible from both the front and back of the cart. The turnkey configuration allows users to get started from the moment Deploy is unboxed.

The 2023 Deploy features an entirely new frame with 16 internal (and replaceable) machined bars that provide a total of 38 integrated 3/8″-16 threaded mounting points for accessory mounting, new aluminum Pull Handles for improved comfort, height adjustable Quick Grips with 360? of rotation, Load Handles that can be mounted to any of the frames 38 mounting points, and a locking bottom drawer.

With a tabletop height of 42.5 in., the Deploy provides a comfortable station for standing workflows. Total working surface expands from 21.125 in. to 45.125 in. with side wings extended. When side wings are collapsed, the Deploy is streamlined, compact, and easily maneuverable. The aluminum top surface of the Deploy is equipped with a 2.5 in. cable passthrough hole for superior cable management and is finished with INOVATIV?s signature black outdoor marine carpet.

The Deploy frame separates in half for simplified transportation and storage. Four removable aluminum side panels protect the inside of the workstation and still allow easy access to internal rack-mounted components. The Deploy is compatible with industry-standard 19 in. rack-mounted systems.

Integrated accessory mounts in several places allow the user to further customize their workstation. Rear Accessory Mounts provide easy connection to INSIGHT Monitor Mount Systems or Two-Stage Risers. A Rear Crossbar supplies additional 3/8″-16 mounting points for accessories like Cable Hooks. Center Mast Bracket provides centered mounting of accessories like the Two-Stage Riser. The Deploy frame features integrated 3/8?-16 threaded mounting points throughout and features 16 replaceable 3/8″-16 accessory bars.

Ideal for both studio and on-location use, the Deploy is fit for travel with INOVATIV?s EVO Wheel System on the front and 20 in. traction wheels in the rear. EVO Wheels swivel for navigation, include foot brakes for safety, and can be removed if needed. The 20 in. rear wheels improve mobility over uneven surfaces or rugged terrain.
Deploy is designed and manufactured in Southern California with premium grade materials and craftsmanship to ensure reliability.

The Motorized Apollo Workstation is a fully integrated system that allows users to effortlessly move payloads up to 1,200 pounds with ease across studios, campuses, and rough terrain to save time and reduce physical strain. It features a complete Apollo workstation cart equipped with the Motorized Wheel System, Hydraulic Brake System, Power Distribution Plate, as well as Top and Bottom Locking Drawers.

The handle throttle assembly powers forward and reverse movement of the dual 10 in. rear wheels, for up to 15 hours or 40 miles of full throttle use. The power supply is integrated into the bottom shelf drawer and provides additional power distribution when charging to USB-A, USB-C and US Type B outlets.

Take full control of the Motorized Apollo Workstation with the Hydraulic Brake System – ideal for maneuvering up or down ramps or hills with precision. This system is lever-actuated from the handle and applies control to the rear wheels for maximum braking power.

The Motorized Apollo is completely tool-less – featuring top and bottom shelves that easily assemble without the use of tools. The Apollo has a fixed height of 40.5 in. providing a comfortable standing height work surface. The shelves feature hemmed edges for safety and boast a 56% increase in thickness compared to our lightweight workstations in order to support heavier payloads. Additionally, the bottom shelf features an internal Main-Frame System, greatly increasing the carts stability and overall payload capacity. The Motorized Apollo continues to meet tough demands with flat proof tires, and corrosion resistant stainless steel and aluminum construction throughout.

The upright tubes are secured using our Corner Mold Lock-System that doubles as a location to mount Apollo specific accessories directly into the carts upright posts, from the top deck. These four vertical posts are 14% thicker than our standard workstation posts and have been positioned at the corners of the cart.

The Top Shelf features four sides and a hinged front panel that quickly opens for comfortable keyboard access. Removable 3/8″-16 and 1/4″-20 Threaded Rail Plates supply mounting additional accessories.
Soft close combo-locking drawers padded with marine carpet are mounted beneath both the top and bottom shelf for safe storage of personal items.

The Apollo uses our Pack Latch System to easily connect the top and bottom shelves together when packed down. The Motorized Apollo is designed so that while the Motorized Wheel System along with the top and bottom shelf remains intact, the top shelf can still be packed down into a more compact configuration.

The Echo is a mobile workstation designed for studio work featuring a height adjustable three-sided top shelf, top and bottom locking drawers, permanent wheels, premium foot brake system, and optional Hydraulic Brake System. The Echo is a partially collapsible workstation cart available in two sizes (36 in. or 48 in.) that can be packed down for storage or transportation.

The three-sided top shelf has an open side for easy access to gear as well as comfortable keyboard use. The work surface of the Echo is equipped with a 2.5 in. cable passthrough hole for superior cable management and is finished with INOVATIV?s signature black outdoor marine carpet. The 3-Sided Top is height adjustable in 2 in. increments, with a minimum height of 38.25 in. and maximum height of 48.25 in., measured from the ground to table surface.

The bottom shelf external mainframe provides stability for an increased payload of up to 1,000 lbs. and incorporates several pass-through holes to house the hydraulic lines of our Hydraulic Brake System. All Echo workstations come standard with two Channel Blocks for mounting additional vertical accessories such as our tripod system or mast riser.

The EVO Wheel System is permanently attached to the Echo for stability and does not quick-release. The 10 in. wheels feature sealed bearings for a smooth ride. Foot Brakes are included standard with the EVO Wheel System.

Users can choose a version of Echo with our one-of-a-kind Hydraulic Brake System, or upgrade later on. The Hydraulic Brake System is lever-actuated from the handle of the Echo and applies control to the rear wheels for maximum braking power and is ideal for maneuvering down ramps or hills with precision. For secure cart parking, lock down both the front EVO Wheel brakes and rear Hydraulic Brakes.

Our tool-less Quick Grip handles are height adjustable and can be rotated 180 degrees for user customized positioning.

Soft close combo-locking drawers padded with marine carpet are mounted beneath both the top and bottom shelf for safe storage of personal items.

The two Accessory Crossbars provide multiple 3/8?-16 mounting points for attaching gear such as our Cable Hooks to the Echo.

The Echo is available in two sizes and four variations: Echo 36, Echo 36 with Hydraulic Brake System, Echo 48, and Echo 48 with Hydraulic Brake System. If you currently own an Echo, the Hydraulic Brake System may be purchased separately here.
