Roland V-1-4K Video Switcher
Roland V-1-4K Video Switcher - Image 2
Roland V-1-4K Video Switcher - Image 3
Roland V-1-4K Video Switcher - Image 4
Roland V-1-4K Video Switcher - Image 5

Roland V-1-4K Video Switcher

Roland
  • Video Processing: 4K60P with HDR Support
  • USB-C Stream / Record (4K60P)
  • Multi-Angle Shots with ROI Feature
  • Video Composition Tools
  • Flexible HDMI Routing
  • Integrated Video Effects
  • PIP / Keyer Layers
  • Deep PTZ Camera Integration
  • Graphics Presenter Softtware
  • VenuSet Software
  • Customisable Control Pads
  • 14 Channel Audio Mixer
  • 1x Video AUX / 1x Audio AUX Buses
  • Inputs: 5x HDMI (Scaled) / 1x XLR
  • Outputs: 5x HDMI (1x Multiview) / 1x Audio / 1x Headphone
  • Control: Web / LAN
  • Remote App Control

$2,695.00

The V-1-4K Video Switcher from Roland is an entry-level video switcher designed for small productions such as house of worship, education, or corporate presentations. The switcher features five HDMI inputs with scalers, five HDMI outputs, a USB-A host connection, and a USB-C streaming output. It supports video resolutions up to UHD 4K60 with HDR support, allowing you to crop and downscale portions of the image without losing quality. A fader, along with multiple dials and knobs, allows complete tactile control of your production.

Scaling and Cropping

The V-1-4K features five HDMI inputs with scalers on every channel, enabling seamless switching between HD and 4K60 HDR video sources. Five HDMI output channels include multiviewer functionality for independent video signals to be fed to a main monitor, a confidence monitor, and other destinations without a distribution amplifier.The ROI (region-of-interest) feature enables you to create multiple shots by cropping specific areas from a single 4K camera source to help reduce setup time and create more shot options for your video production. The V-1-4K Remote/RCS app helps your cropping area setup with intuitive operation.

Flexible Routing
There are five video inputs and six total outputs (HDMI plus USB streaming) that offer flexibility for a wide range of production needs. In addition to program, preview, and multiview outputs, output channels 3 and 4 can be assigned to any output bus and any input signal via 4K-to-HD downscalers.
Plug-and-Play Streaming
The V-1-4K uses the same connection technology as webcams for plug-and-play video streaming. Connect the USB-C output to a computer and start streaming with Zoom, Microsoft Teams, or any streaming platform that supports a standard webcam connection.
Video Composition Tools
The V-1-4K makes it simple to keep audiences engaged with layered graphics and visual effects. Three composition layers allow you to use scalable picture-in-picture images and add titles, logos, social media comments, and more.
PTZ Camera Integration
The V-1-4K includes built-in control support for select Canon, JVC, Panasonic, Sony, PTZOptics, Avonic, and VISCA-compatible PTZ IP-based cameras. Mix and match different brands and operate up to five PTZ cameras simultaneously. The V-1-4K Remote app for iPad provides PTZ operation, allowing you to control remote cameras from the tablet.
Free Companion Software

Graphics Presenter is a Windows-based software that allows you to create stunning titles and motion graphics with compatible Roland video switchers. VenuSet for iPadOS/macOS/Windows allows a customizable solution that makes it easier to operate the V-1-4K.V-1-4K RCS for macOS and Windows and V-1-4K Remote for iPadOS provide full software control of the V-1-4K switcher via LAN or USB host connections.

Audio Mixing and I/O

The V-1-4K features 14 channels of audio mixing and a wide selection of processing tools, including equalizers and compressors. There are also sync delays on all input and output busses to align audio with video if needed. I/O routing options include main, monitor, and two aux buses for complex audio configurations.The switcher supports analog audio input via dual XLR inputs, and it can output/extract audio via the two RCA outputs and a 3.5mm headphone jack.



Customizable Control Pads
Eight user-assignable pads provide instant control of many functions during live events. The pads are organized into four banks, providing direct access to 32 operations, including video input routing, audio muting, system configuration access, and more. You can also control functions in the Graphics Presenter software when the host computer is connected via USB.
SKU: ROL-V-1-4K Category: Brand:
