TecArt LEDrive CC 6 DIN Rail 0-10V
LEDrive CC 6 DIN Rail is a constant current LED dimmer, utilising 0-10V analogue control. The unit is flicker free and film and TV compatible. The unit has 6 channels of output, for use with up to 1200mA LEDs.
LEDrive CC 6 DIN Rail can be supplied with an external 12 – 48VDC power supply.
FEATURES
• 0-10V control input.
• External power supply 12 – 48VDC.
• Terminal strip output.
SPECIFICATIONS
• Input voltage: 10 – 48VDC.
• Power supply: External.
• Dimensions: 110mm (L) x 90mm (W) x 60mm (H).
• Mounting method: DIN Rail.
• Control input: Terminal strip.
• Outputs: 6 channels.
• Driving capacity: Up to 1200mA per channel.
• Temperature: 0 – 40 degrees Celsius.
